Product Description
This JET large capacity variable speed semi-automatic horizontal bandsaw is loaded with features that allow the operator the ability to fine tune the blade speed easily and quickly on a convenient swing away control panel. The sturdy head raises automatically after each cut and cast iron band wheels give you the confidence of quality cuts, first time, every time.
Features
- Swivel control panel houses major saw controls
- Adjustable blade guide with six contact point system that utilizes cam follower bearings mounted on eccentric shafts on both sides of the blades
- Downfeed system is controlled by a dual system of counterbalance springs working with a hydraulic cylinder
- Saw head raises hydraulically after each cut
- Variable speed drive system allows the operator to easily fine tune the blade speed
- Heavy-Duty transmission utilizes hardened and ground gears operating in an oil bath
- Cast Iron blade wheels
- Patented 3-Jaw rapid action vise for faster set up
- Coolant system
- Adjustable material stop
- 1" Bi-Metal blade
Specification
| Cutting Capacity (W x D) (In.) | 12 x 20 |
| Round at 90 Degrees (In.) | 12 |
| Round at 45 Degrees (In.) | 12 |
| Rectangle at 90 Degrees (In.) | 12 x 20 |
| Rectangle at 45 Degrees (In.) | 12 x 12 |
| Vise Swivels (Deg.) | 45° |
| Blade Speeds (SFPM) | 82 - 262 |
| Blade Wheel Diameter (In.) | 17 |
| Blade Length (In.) | 156 |
| Blade Size (In.) | 1 x .035 x 156 |
| Bed Height (In.) | 26-1/4 |
| Motor (HP) | 3 HP, 460V, 3Ph |
| Weight (Lbs.) | 1,456 |
| Overall Dimensions (L x W x H) (In.) | 87 x 37-1/2 x 53 |
